HANGMO · TPU SERIES CUTTING FILM

The TPU family, one page

TPU-HD clear · TPU-MATTE matte · TPU-BLUECUT blue-cut · TPU-PRIVACY privacy · TPU-FOLD foldable. Launched tiers all show QC-measured figures.

SERIES 01 · CLEAR

TPU-HD

Clear · BASIC / PRO / ULTRA · all measured
BASIC TPU BASIC film print · TA35147TW-1 · Clearest · haze 0.25%
BASICTA35147TW-1 · Clearest · haze 0.25%
PRO TPU PRO film print · TA35156TW-8 · Strongest adhesion · 1087g
PROTA35156TW-8 · Strongest adhesion · 1087g
ULTRA TPU ULTRA film print · TA35128TT · Slickest · COF 0.12
ULTRATA35128TT · Slickest · COF 0.12
Hover a card to light up its column · Click to open its data page
REAL QC DATA · MEASURED

Head-to-head specs

悬停卡片或参数查看对应数据
SPEC · QC MEASURED
BASICTA35147TW-1
PROTA35156TW-8
ULTRATA35128TT
Applications
Model films Cutting films
Model films Cutting films
Model films Cutting films
Transmittance
93%
93%
92.9%
Haze
0.25%
0.5%
0.7%
Contact angle
105°
108°
117°
COF
0.151
0.14
0.12
Steel adhesion
825g
1087g
729g
Cross-hatch
5B
5B
5B
Thickness
148μm
149μm
148μm
Open BASIC data sheet ↗TA35147TW-1 · Clearest · haze 0.25% Open PRO data sheet ↗TA35156TW-8 · Adhesion 1087g Open ULTRA data sheet ↗TA35128TT · Slickest · COF 0.12

All figures are QC-measured; bars are scaled to each row's best value (Haze / COF: lower is better, inverted).

SERIES 02 · MATTE

TPU-MATTE

Matte anti-glare · PRO / ULTRA · both measured
PRO TPU PRO film print · TA35156AG-5 · Anti-glare matte · adhesion 1415g
PROTA35156AG-5 · Anti-glare matte · adhesion 1415g
ULTRA TPU ULTRA film print · TA35128AG · Ultra-slick matte · COF 0.099
ULTRATA35128AG · Ultra-slick matte · COF 0.099
Hover a card to light up its column · Click to open its data page
REAL QC DATA · MEASURED

Head-to-head specs

悬停卡片或参数查看对应数据
SPEC · QC MEASURED
PROTA35156AG-5
ULTRATA35128AG
Applications
Model films Cutting films
Model films Cutting films
Transmittance
92.8%
91.6%
Contact angle
109°
110°
COF
0.21
0.099
Steel adhesion
1415g
1450g
Cross-hatch
5B
5B
Haze
52.3%
62.6%
Functional thickness
137μm
146μm
Open PRO data sheet ↗TA35156AG-5 · 137μm measured · adhesion 1415g Open ULTRA data sheet ↗TA35128AG · 146μm measured · COF 0.099

PRO / ULTRA are both QC-measured; bars are scaled to each row's best value (COF: lower is better, inverted).

SERIES 03 · BLUE-CUT

TPU-BLUECUT

Blue-cut · PRO / ULTRA · both measured
PRO TPU PRO film print · TA35156BLC-2 · Blue-cut · blocking 21.3%
PROTA35156BLC-2 · Blue-cut · blocking 21.3%
ULTRA TPU ULTRA film print · TA35146BLC · 410nm blocking 23.3%
ULTRATA35146BLC · 410nm blocking 23.3%
Hover a card to light up its column · Click to open its data page
REAL QC DATA · MEASURED

Head-to-head specs

悬停卡片或参数查看对应数据
SPEC · QC MEASURED
PROTA35156BLC-2
ULTRATA35146BLC
Applications
Model films Cutting films
Model films Cutting films
Transmittance
92.8%
92.7%
Blue-light blocking
21.3%
23.3%
Contact angle
98°
104°
COF
0.25
0.12
Steel adhesion
1300g
580g
Cross-hatch
5B
5B
Functional thickness
125μm
145μm
Open PRO data sheet ↗TA35156BLC-2 · 125μm measured · blocking 21.3% Open ULTRA data sheet ↗TA35146BLC · 145μm measured · blocking 23.3%

PRO / ULTRA are both QC-measured; bars are scaled to each row's best value (COF: lower is better, inverted).

SERIES 04 · PRIVACY

TPU-PRIVACY

Matte privacy · PRO / ULTRA · both measured
PRO TPU PRO film print · PA36168AG-F · Matte privacy · 65.2% trans
PROPA36168AG-F · Matte privacy · 65.2% trans
ULTRA TPU ULTRA film print · PA36168AG-F-2 · Privacy · 68.3% trans
ULTRAPA36168AG-F-2 · Privacy · 68.3% trans
Hover a card to light up its column · Click to open its data page
REAL QC DATA · MEASURED

Head-to-head specs

悬停卡片或参数查看对应数据
SPEC · QC MEASURED
PROPA36168AG-F
ULTRAPA36168AG-F-2
Applications
Model films Cutting films
Model films Cutting films
Transmittance
65.2%
68.3%
Haze
54.9%
50.8%
Contact angle
104°
106°
COF
0.22
0.12
Steel adhesion
1091g
1307g
Cross-hatch
5B
5B
Functional thickness
161μm
158μm
Open PRO data sheet ↗PA36168AG-F · 161μm measured · privacy Open ULTRA data sheet ↗PA36168AG-F-2 · 158μm measured · privacy

PRO / ULTRA are both QC-measured; bars are scaled to each row's best value (transmittance: lower is more private; COF: lower is better, inverted).

SERIES 05 · FOLDABLE

TPU-FOLD

Foldable · ULTRA measured · 200K fold cycles
ULTRA TPU ULTRA film print · TS35135ST · 200K folds · COF 0.086
ULTRATS35135ST · 200K folds · COF 0.086
Hover a card to light up its column · Click to open its data page
REAL QC DATA · MEASURED

Measured specs

悬停卡片或参数查看对应数据
SPEC · QC MEASURED
ULTRATS35135ST
Applications
Foldable films Cutting films
Transmittance
93.4%
Haze
0.32%
Contact angle
114°
COF
0.086
Steel adhesion
558g
Cross-hatch
5B
Thickness
102μm
Open ULTRA data sheet ↗TS35135ST · 102μm measured · 200K fold cycles

All figures are QC-measured (FOLD6 / FOLD8 real-device edge-lift test OK).

MODEL INDEX · 10 GRADES · ALL QC MEASURED

All TPU models — every grade has its own QC data sheet

Thermoplastic polyurethane film — flexible, self-healing, and the widest grade matrix in the range. The default route for curved screens and daily-wear phones.

TPUFlexible · self-healing base
TPU-HD · Clear3 grades
TPU-HD BASIC Model TA35147TW-1 Clearest grade · haze 0.25% BASIC TPU-HD PRO Model TA35156TW-8 Adhesion 1087g PRO TPU-HD ULTRA Model TA35128TT Slickest · COF 0.12 ULTRA
TPU-MATTE · Anti-glare2 grades
TPU-MATTE PRO Model TA35156AG-5 137μm measured · adhesion 1415g PRO TPU-MATTE ULTRA Model TA35128AG 146μm measured · COF 0.099 ULTRA
TPU-BLUECUT · Blue-light filtering2 grades
TPU-BLUECUT PRO Model TA35156BLC-2 125μm · 410nm blocking 21.3% PRO TPU-BLUECUT ULTRA Model TA35146BLC 145μm · 410nm blocking 23.3% ULTRA
TPU-PRIVACY · Matte privacy2 grades
TPU-PRIVACY PRO Model PA36168AG-F 161μm measured · privacy PRO TPU-PRIVACY ULTRA Model PA36168AG-F-2 158μm measured · privacy ULTRA
TPU-FOLD · Foldable1 grade
TPU-FOLD ULTRA Model TS35135ST 102μm · 200K fold cycles ULTRA

Every figure above is measured in our own cleanroom and published on the model page. Compatible with all compact cutting plotters — no model limits. Need a size, thickness or coating not listed here? Send your spec and we will quote it.
